北京卅普科技有限公司简介

高频晶闸管、快速晶闸管、普通晶闸管、晶闸管模块、整流管模块，销售电话：010 - 65120098 13910791420 吕工 13552457401 刘工

清华大学电力电子厂（简称“THUpE”、“清华卅普”，暨清华大学核能与新能源技术研究院功率电子技术研究室），是一家以电力电子技术为核心，以功率半导体器件、感应加热电源为主导的科技型企业，是目前业界公认的国产KA高频晶阐管、表面热处理（热加工）感应加热电源及成套设备制造商和提供商，是2008年北京市科委重新认定的首批高新技术企业之一，是清华大学全资企业。

30年来，清华卅普始终站在科技创新前沿，成为国内KA高频晶阐管、大功率感应加热电源的者。近几年开展元件生产线贯彻国军标的工作，先后承担了：1条元件生产线贯彻国军标；2个军品元器件国产化项目；1个工信部电子发展基金项目；有9个科技成果荣获省、部级以上科技奖；主持或参与4项行业标准的制订、修订；获得了12项国家专利。

清华卅普已经建成了一支较强的研究开发团队，在新型电力电子元件及感应加热电源开发方面不断开发出新产品，如150A/150V功率MOSFET、150kW/250kHz高频感应加热电源、混凝土管桩及高铁轨枕用预应力钢棒生产线等。目前清华卅普研发团队已有近20人，包括：1名博士后出站、4名硕士；2名研究员、1名副研究员、4名高工；2名电工技术学会电力电子学会理事；2名兼职博士生导师、1名硕士生导师。

The Power Electronics Plant of Tsinghua University (referred to as "THUpE", "Tsinghua Sapu", and the Power Electronics Technology Research Office of the Nuclear Energy and New Energy Technology Research Institute of Institute of Nuclear and New Energy Technology) is a scientific and technological enterprise with power electronics technology as the core and power semiconductor devices and induction heating power supply as the leading factor. It is currently recognized by the industry as a domestic KA high-frequency transistor The manufacturer and supplier of induction heating power supply and complete equipment for surface heat treatment (Hot working) is one of the first high-tech enterprises re recognized by the Beijing Municipal Science and Technology Commission in 2008, and is a wholly-owned enterprise of Tsinghua University.

For 30 years, Tsinghua Sapu has always been at the forefront of technological innovation, becoming a domestic leader in KA high-frequency thyristors and high-power induction heating power supplies. In recent years, we have carried out the work of implementing the national military standard on component production lines, and have successively undertaken the following tasks: 1 component production line implements the national military standard; 2 localization projects for military components; 1 Electronic Development Fund project of the Ministry of Industry and Information Technology; 9 scientific and technological achievements have won science and technology awards at the provincial or ministerial level or above; Lead or participate in the formulation and revision of four industry standards; Obtained 12 national patents.

Tsinghua SAP has built a strong research and development team, and has continuously developed new products in the development of new power electronic components and induction heating power supply, such as 150A/150V Power MOSFET, 150kW/250kHz high-frequency induction heating power supply, concrete pipe piles and production lines of prestressed steel bars for high-speed railway sleepers. At present, there are nearly 20 members in the research and development team of Tsinghua Sanpu, including: 1 postdoctoral candidate and 4 master's candidates; 2 researchers, 1 associate researcher, and 4 senior engineers; 2 members of the Power Electronics Society of the Electrotechnical Society; 2 part-time doctoral supervisors and 1 master's supervisor.

普通晶闸管：

型号	V_DRM/V_RRM	I_TSM	I_GT	V_GT	V_TM/I_TM	V_TO	r_T	R_th(j-c)	R_th(c-hs)	T_jm	安装力
型号		10 ms	25 °C			125 °C
	V	KA	mA	V	V/A	V	mΩ	°C/W	°C/W	°C	kN
电压至2000V
200A	400-2000	4.65	30-200	0.8-2.0	2.1/600	0.85	1.20	0.080	0.020	125	3.3-5.5
300A	400~2000	7.5	35-250	0.8-2.5	2.0/900	0.88	0.8	0.040	0.010	125	5.3-10
500A	400~2000	11	35-300	0.8-2.5	2.0/1500	0.85	0.42	0.035	0.008	125	10-20
800A	400~2000	12	40-300	0.8-3.0	2.2/2400	0.91	0.35	0.028	0.0075	125	15-20
1000A	400~2000	13	40-300	0.8-3.0	2.2/3000	0.93	0.29	0.024	0.006	125	18-25
1200A	400~2000	24	40-300	0.8-3.0	2.10/3000	0.91	0.23	0.020	0.005	125	19-26
1600A	400~2000	26	40-300	0.8-3.0	2.0/3000	0.95	0.18	0.018	0.004	125	21-30
1800A	400~2000	30	40-300	0.8-3.0	2.10/4000	0.98	0.15	0.016	0.004	125	21-30
2000A	400~2000	35	40-300	0.8-3.0	2.0/4000	0.87	0.14	0.013	0.0035	125	27-34
2500A	400~2000	38	40-300	0.8-3.0	2.0/5000	0.80	0.14	0.012	0.003	125	30-40
3000A	400~2000	51	40-300	0.8-3.0	1.80/5000	0.84	0.09	0.010	0.003	125	35-47
电压至3000V
500A	2000~3000	10	40-300	0.8-3.0	2.4/1500	1.2	0.78	0.028	0.0075	125	15-20
1000A	2000~3000	20	40-300	0.8-3.0	2.4/2400	1.11	0.36	0.020	0.005	125	19-26
1200A	2000~3000	18	40-300	0.8-3.0	2.4/3000	0.97	0.27	0.018	0.004	125	21-30
1500A	2000~3000	23.6	40-300	0.8-3.0	2.3/3000	0.98	0.21	0.016	0.004	125	21-30
2000A	2000~3000	28	40-300	0.8-3.0	2.3/4000	1.07	0.19	0.012	0.0035	125	30-40
2500A	2000~3000	32	40-300	0.8-3.0	2.4/5000	1.05	0.18	0.010	0.003	125	35-47
3500A	2000~3000	44	40-300	0.8-3.0	2.1/5000	0.99	0.11	0.007	0.002	125	63-84
4000A	2000~3000	65	40-300	0.9-3.5	1.90/5000	0.91	0.09	0.005	0.0015	125	81-108
电压至4000V
400A	3000~4000	7	35-300	0.8-2.5	3.0/1000	1.18	1.00	0.035	0.008	125	10-20
800A	3000~4000	13	40-300	0.8-3.0	2.5/1500	1.14	0.57	0.020	0.005	125	19-26
1200A	3000~4000	20	40-300	0.8-3.0	2.6/3000	1.17	0.35	0.013	0.035	125	27-34
1500A	3000~4000	27	40-300	0.8-3.0	2.30/3000	1.15	0.28	0.010	0.003	125	35-47
2500A	3000~4000	40	40-300	0.8-3.0	2.6/5000	1.0	0.18	0.007	0.002	125	63-84
3000A	3000~4000	60	40-300	0.8-3.0	2.4/5000	0.88	0.12	0.005	0.0015	125	81-108
电压至5000V
400A	4000~5000	4.5	35-300	0.8-3.0	3.2/900	1.45	1.15	0.035	0.008	125	10-20
700A	4000~5000	10	40-300	0.8-3.0	3.2/1500	1.04	0.84	0.020	0.005	125	19-26
1000A	4000~5000	17	40-300	0.8-3.0	3.0/3000	1.30	0.58	0.013	0.0035	125	27-34
1500A	4000~5000	24	40-300	0.8-3.0	2.8/3000	1.30	0.35	0.010	0.003	125	35-47
2000A	4000~5000	34	40-300	0.8-3.0	2.2/3000	1.09	0.24	0.009	0.002	125	63-84
3000A	4000~5000	45	40-300	0.8-3.0	2.8/5000	1.13	0.21	0.005	0.0015	125	81-108

快速晶闸管：

型号	V_DRMV_RRM	t_q	I_TSM	dv/dt	di/dt	V_TM/I_TM	V_TO	r_T	R_th(j-c)	R_th(c-hs)	T_jm	安装力
型号		125 °C	10ms	125 °C		25 °C	125 °C
	V	μs	KA	V/μs	A/μs	V/A	V	mΩ	°C/W	°C/W	°C	kN
电压至2000V
300A	800-1800	18-50	4.3	500	1200	3.0/900	1.60	1.32	0.045	0.010	125	5.3-10
500A	800-1800	18-50	9.0	500	1200	3.15/1500	1.36	0.53	0.035	0.008	125	10-20
600A	800-1800	18-50	10	500	1200	3.15/1800	1.30	0.38	0.028	0.0075	125	15-20
800A	800-1800	18-50	12	500	1200	3.15/2400	1.32	0.36	0.024	0.006	125	18-25
1000A	800-1800	18-50	14	500	1200	3.15/3000	1.56	0.33	0.020	0.005	125	19-26
1200A	800-1800	18-50	16	500	1200	3.15/3000	1.51	0.32	0.018	0.004	125	21-30
1500A	800-1800	18-50	18	500	1200	3.15/3000	1.48	0.28	0.016	0.004	125	21-30
1800A	800-1800	18-50	21	500	1200	3.15/4000	1.41	0.23	0.013	0.0035	125	27-34
2000A	800-1800	30-60	23	500	1200	3.15/4000	1.45	0.21	0.012	0.003	125	30-40
2500A	800-1800	30-60	35.6	500	1200	3.15/5000	1.30	0.15	0.010	0.003	125	35-47
电压至3000V
1600A	1900-3000	40-80	21	500	1200	3.15/3600	1.48	0.23	0.013	0.0035	125	27-34
2000A	1900-3000	40-80	22.7	500	1200	3.15/4000	1.48	0.15	0.012	0.003	125	30-40
2500A	1900-3000	40-80	33.8	500	1200	3.15/5000	1.48	0.14	0.010	0.003	125	35-47
3000A	1900-3000	40-110	44	500	1200	3.0/5000	1.32	0.13	0.007	0.002	125	63-84
4000A	1900-3000	40-120	62	500	1200	2.90/5000	1.30	0.28	0.005	0.0015	125	81-108
电压至5000V
1600A	3000-5000	50-100	18	1000	1000	3.4/2000	1.65	0.38	0.012	0.003	125	30-40
2000A	3000-5000	50-100	23	1000	1000	3.4/2000	1.89	0.42	0.01	0.003	125	35-47
1800A	3000-5000	60-50	25	1000	500	3.2/2000	1.68	0.26	0.01	0.003	125	35-47
2000A	3000-5000	50-150	30	1000	500	3.2/2200	1.58	0.17	0.007	0.002	125	63-84
2500A	3000-5000	60-150	40	1000	500	3.4/2500	1.58	0.15	0.005	0.0015	125	81-108

高频晶闸管：

型号	I_TAV Sine wave 10 kHz Tc=65℃	V_DRM V_RRM	V_TM at 3I_TAV 25℃	V_GT 25℃	I_GT 25℃	t_q 125℃	t_gt 25℃	di/dt (at 10kHz) 25℃	dv/dt 125℃	R_jc	f_m Sine wave Tc=65℃	F 安装力
型号	（A）	（V）	（V）	(V)	(mA)	(μs)	(μs)	(A/μs)	(V/μs)	(℃/W)	kHz	kN
电压至1600V
KA20	20	300 - 1600	3.2	2	120	10	2.5	60	500	0.4	20
KA35	35	300 - 1600	3.2	2	120	10	2.5	80	500	0.2	20
KA50	50	300 - 1600	3.2	2	150	10	2.5	80	500	0.11	20
KA100	100	300 - 1600	3.2	2	150	10	2.5	100	500	0.08	20	8
KA200	200	300 - 1600	3.2	2	200	15	3	200	800	0.05	10	8
KA300	300	300 - 1600	3.2	2	200	15	3	200	800	0.04	10	12
KA400	400	300 - 1600	3.2	2	200	15	3	200	800	0.035	10	16
KA500	500	300 - 1600	3.2	2	200	15	3	200	800	0.026	10	18
KA600	600	300 - 1600	3.2	3	250	15	4	200	800	0.026	10	18
KA800	800	300 - 1600	3.2	3	250	15	4	300	800	0.022	10	22
KA1000	1000	300 - 1600	3.2	3	250	20	4	300	800	0.020	10	24
KA1200	1200	300 - 1600	3.2	3	250	20	4	300	800	0.015	10	28
KA1600	1600	300 - 1600	3.2	3	250	20	4	300	800	0.012	10	36
KA2000	2000	300 - 1600	3.2	3	250	20	4	300	800	0.010	10	48
